Key Features
- 3MP HD quality, capture every detail
- Built-in speaker + Mic, two-way voice real-time intercom, as real as face-to-face
- One-click physical shielding to protect user privacy
- One-key to call family member, open two-way real-time voice intercom or video call
- Support AP Hotspot, QR code + Sound wave auxiliary Wi-Fi setting
- Support Region Intrusion, Line Crossing, Humanoid Tracking
- Support Micro SD card storage up to 256GB
- Support ONVIF protocol
Specifications
| Video | |
| Image Sensor | 1/2.8″ CMOS Sensor |
| Max Resolution | 2304×1296 |
| Effective Pixels | 3.0MP |
| Compression Standard | H.264/H.265 |
| Frame Rate | 25fps |
| Bitrate | Main Stream: 256Kbps ~ 4096Kbps
Sub Stream: 68Kbps~1024Kbps |
| SNR (dB) | 52dB |
| Min. Illumination | 0Lux (IR ON) |
| Lens | |
| Interface Type | M12 |
| Lens | 4mm |
| FOV | 4mm:H 87°, V 41°, D 93° |
| Function | |
| Audio Codec | G.711U/G.711A (Default) |
| One-key Calling | Support |
| PTZ Calibration | Support |
| Privacy Masking | Support |
| Hourly Chime | Support |
| Exposure Control | Auto |
| White Balance | Auto |
| Gain Control | Auto |
| Digital 3D Noise Reduction | Support |
| OSD Information Setting | Large font OSD, OSD flashing on alarm, OSD position settings |
| SNTP | Support |
| Schedule Reboot | Support |
| Motion Detection | Support |
| Image Setting | Support Saturation, Brightness, Contrast, Sharpness adjustment |
| Image Style | Standard, Soft, Transparent |
| Day and Night Function | Auto Switching, Schedule Switching, Day Mode, Night Mode |
| Privacy Mask | Support up 8 areas |
| Electronic Screen Setting | Support Max & Min Exposure Time setting |
| Night Vision Optimization | Support |
| DWDR | Support |
| Screen Settings | Screen Mirroring, Screen Flipping |
| IP Adaptation | Support automatic adaptation of IP address |
| Intelligent Analysis | Support Region Intrusion, Line Crossing, Humanoid Tracking |
| Alarm Method | Email Alarm, Client Alarm, Mobile APP push |
| Remote Operation | System, Audio and Video, Image, Alarm, Network management, Storage management, Intelligent Analysis |
| SD Card | Up to 256GB |
| Pan/Tilt | H:347°; V: 86° (-35° ~ 51°) |
| Network | |
| Wireless Protocol | IEEE 802.11b/g/n 2.4GHz |
| Stream | 2x Streams |
| Network Protocols | HTTP, TCP/IP, UDP, ICMP, RTSP, RTP, RTCP, SMTP, DHCP, DNS |
| ONVIF | Standard ONVIF |
| Network Transmission | CloudSEE 2.0 |
| Browser | IE8+, Chrome18+, Firefox5.0+, Safari 5.02+ |
| User | Up to 13 Users |
| General | |
| Lights | 1pcs IR LED |
| IR Distance | Up to 10m |
| Status Indicator | Support, Red & Blue Indicator |
| Power Supply | DC 5V/1.5A |
| Power Consumption | ≤5.42W |
| Working Temperature | -10°C ~ 55°C |
| Working Humidity | 10% ~ 95% Rh, non-condensing |
| Color/Material | White, ABS+PC |
| Dimensions (WxHxD) | 75.5×75.5×115.5mm |
| Weight | 175g |
| Installation Method | Desktop, Ceiling mount |
| Packing Quantity | 40 sets/box |
